| Deviation in Length & Width |
EN 98 /ISO 10545-2 |
±0.5% |
± 0.4 % |
| Thickness |
EN 98 /ISO 10545-2 |
± 5 % |
± 3.0 % |
| Straightness of side |
EN 98 /ISO 10545-2 |
± 0.3 % |
± 0.2 % |
| Rectangulary |
EN 98 /ISO 10545-2 |
±0.5% |
± 0.2 % |
| Surface Flatness (warpage) |
EN 98 /ISO 10545-2 |
±0.5% |
± 0.2 % |
| Water Absorption |
EN 99 /ISO 10545-3 |
Group Blₐ, E ≤ 0.5% |
Group Blₐ, E ≤ 0.05 |
| Modulus Of Rupture |
EN 100 /ISO 10545-4 |
min. 35 N/mm², individual min 32 |
min. 45 N/mm² |
| Scratch hardness of surface(Mohs) |
EN 101 |
≥ 5 |
≥ 6 |
| Coefficient of linear Thermal Expansion from ambient temp. to 100°C |
EN 103 /ISO 10545-8 |
Max 9X10¯⁶ x K¯¹ |
Max 7.5X10¯⁶ x K¯¹ |
| Resistance to Thermal Shock |
EN 104 /ISO 10545-9 |
10 cycle min. |
Passed 10 cycle. |
| Moisture Expansion in mm/m |
EN 155 /ISO 10545-10 |
N.A. |
N.A. |
| Crazing Resistance(Glazed) |
EN 105 /ISO 10545-11 |
4 cycle@7.5 bar min |
Passed 4 cycle. |
| Frost Resistance |
EN 202 /ISO 10545-12 |
No Damage |
No Damage |
| Chemical Resistance(Glazed) |
EN 122 /ISO 10545-13 |
Min class AA |
Min class AA |
| Staining Resistance(Glazed) |
EN 122 /ISO 10545-14 |
Min class 1 |
Min class 1 |
| Color Resistance to Light |
Exposing 60 Watt (20 nos) Tungsten Lamp for 24 Hours |
As Per Manufacturer |
No change in brightness or clolor occurred |
| Visual Inspection |
--- |
Min 95% tiles will be free from visual defects. |
Min 95% tiles will be free from visual defects. |
